DESCRIPTION

Overview

Basic Info.

Model NO.	HYL5057JGKQ60
Payload	5t
Fuel	Diesel
Transmission Type	Manual
Drive Wheel	4x2
Condition	New
Name 2	Cherry Picker
Name 3	Manlift, Truck Lift
Name 1	Truck Bucket
Wheel Base	3360mm
Transport Package	Wax Spray
Specification	6410*1990*3040 mm
Trademark	AICHI
Origin	China
HS Code	8705909990
Production Capacity	1000/Year

Product Description

Product Description

BASIC INFO.

Model NO.	HYL5057JGKQ60	Feature	Articulating non-Insulation
Certification	ISO 9001, CCC	Rated Load of Work Platform	200 kg
Max. Work Height	14.2 m	Transport Package	Comply with Export Packaging Requirements
Outline dimension	6410*1990*3040 mm	Trademark	AICHI
Origin	Zhejiang, China	Production Capacity	1000 Unit

Detailed Photos

Product Parameters

TECHNICAL PARAMETERS

G.V.W.	5320kg
Bucket
Max. work height	14.2m
Max. bucket floor height	12.5m
Max. work radius	7.1m
Bucket load	200kg
Boom
Type	Three sections articulated
Rotation angle	360°
Outrigger
Type	H
Adjustment	Adjusted separately
Chassis
Model	QL1070BUHWY
Cabin	Double, 4-doors
Seat capacity	5 persons
Wheelbase	3360 mm
Steering	Power steering, L.H.D.
Engine
Model	4KH1CN6LB
Engine power	88 kW
Discharge Standard	Euro 6
Fuel	Diesel
Hook (Optional)
Max.lifting weight	990kg
Max.lifting height	7.3m

Certifications Company Profile

Hangzhou Aichi Engineering Vehicles Company was established in April, 1995, which is a joint venture company invested by Aichi Corporation, Japan and Hangzhou Gardening Machinery Factory (owned by local government).
The company has more than 200 staff and covers an area of 53,000 square meters. Approx. 600 units of aerial work platforms (herein called AWP) can be sold annually, and the sales amount exceeds 300 million RMB Yuan.
The products are widely applied in street light repairing, electricity, utility, expressway, telecommunication, construction, gardening, airport, advertising, port and also companies, universities.
The products have been sold all over the country, and also exported to Russia, Cuba, North Korea, Bangladesh, Ecuador, Philippines, Australia, Vietnam, Thailand, Kazakhstan, Mongolia, Malaysia, Brunei, Kyrgyzstan, Turkmenistan, Grenada, Angola and etc., which get good reputation from the customers.

Our Advantages

PERFORMANCE CHARACTERISTICS:
1. Stabilizers and boom has interlocking device:
If the stabilizers are not grounded or effectively touched, the upper cannot be operated; when the upper is in the operation state, the outriggers cannot be operated.
2. Emergency power-off switch:
There is an emergency off switch at the bucket and the turntable respectively. In case of an emergency, you can press this switch to cut off the power, cut off the oil circuit and stop the engine to stop all movements.
3. The max. stretch angle of the boom reaches 90° to adjust to the best working position.
4. The upper and lower operating systems can complete various operation actions on the bucket and on the turntable.
5. The outriggers can be adjusted separately, and each outrigger can be adjusted separately according to the working ground environment. Even if the ground is uneven, the vehicle can be adjusted to a horizontal state.
6. Both elevation and rotary movements can achieve stepless speed regulation, that is, in the upper and lower operating systems, the speed of elevation and rotation actions can be achieved from zero to maximum, so that the vehicle can move smoothly in the operation and make the operators safer and more comfortable.
7. The work lights are installed on the upper and lower control boxes. The bucket is equipped with headlights for night work.
8. The worm box with available screws to adjust the position is used in the rotary mechanism. As long as the screws are tightened or relaxed, the worm box can cooperate more closely with the rotary support, which is convenient for future maintenance.
